Technical Data
|
SIZES
|
22
|
24
|
26
|
28
|
30
|
|---|---|---|---|---|---|
|
Number of cells
|
40
|
40
|
40
|
40
|
40
|
|
Projected area (m2)
|
18.7
|
20.3
|
22.1
|
24
|
26.1
|
|
Flat Area (m^2)
|
22
|
23.9
|
26
|
28.3
|
30.7
|
|
Projected Span (m)
|
8.05
|
8.39
|
8.75
|
9.12
|
9.51
|
|
Flat Span (m)
|
10.39
|
10.83
|
11.29
|
11.77
|
12.27
|
|
Projected Aspect Ratio
|
3.46
|
3.46
|
3.46
|
3.46
|
3.46
|
|
Flat Aspect Ratio
|
4.9
|
4.9
|
4.9
|
4.9
|
4.9
|
|
Root Chord (m)
|
2.72
|
2.83
|
2.95
|
3.08
|
3.21
|
|
Glider Weight (kg)
|
4.45
|
4.66
|
4.97
|
5.28
|
5.6
|
|
PG (EN) Weight Range (kg)
|
55-70
|
65-85
|
80-100
|
95-115
|
110-130
|
|
PPG Weight Range (kg)
|
55-90
|
65-110
|
80-130
|
95-150
|
110-165
|
|
Certification EN*
|
–
|
A*
|
A*
|
A*
|
–
|
|
DGAC
|
DGAC
|
DGAC
|
DGAC
|
DGAC
|
DGAC
|
*tested to the EN 926.2 standard with the trimmers locked and within PG weight range.
* Weights may vary up to 50gm per size due to slight variations in the manufacturing of the fabric used.
